Yanmar KM2P-1 Kanzaki Marine Transmission 2.21:1 Ratio Mechanical Boat Inboard
By Yanmar
PART #128171-81310
WARRANTY1 Year
MADE INJapan
SHIPPING WT25 lbs
SHIPPING DIMS16" x 16" x 14"
$2,465.78
Free Shipping to the Contiguous 48 US States
Out of stock
Share this product:
PinterestTwitterFacebook
Product Description
New Yanmar KM2P-1 marine transmission. Manufactured by Kanzaki in Japan. Gear ratio is 2.21:1. Comes painted Yanmar gray. Was originally installed onto a Yanmar engine and removed by the factory. Does not come with any accessories.

This transmission is sold by an official dealer with full warranty support. Commonly used on Yanmar 2GM20, 2YM20, and 3YM30 marine diesel engines.

Important Guidelines
To improve transmission longevity and preserve the warranty, please follow these guidelines when installing and running your new transmission:

Oil Cooler
For transmissions that use an oil cooler, it is important to have it serviced or buy a new one (and flush the oil lines). If there had ever been water, metal particles, or other debris in the old transmission oil, or the old transmission failed or was slipping, reusing an old oil cooler can cause debris to enter the new transmission through the cooler circuit, which can void the warranty and lead to premature failure. The ZF complete cooler kit for the 63, 68, 63A, and 68A model transmissions is part number 3312107001, available here.

If you need a new oil cooler, you can view a list of coolers here. The oil cooler used by the transmission will vary depending on the engine make and model, so yours may not be listed. Contact for help if needed.

Damper Plate
Also called a drive plate, this bolts to the flywheel and engages the transmission input splines. It dampens the engine torsional firing impulses to protect the transmission. An old, damaged, or worn out damper plate may not dampen the torsionals as well, leading to premature wear and tear, or in the worst case a complete failure. If you need a new damper, you can view a list of dampers here.

If you're changing from a Volvo MS-series transmission to a ZF, you'll also need to switch from the original spring type to a Centa bushing type damper.

Oil Changes & Fluid Types
Check your transmission oil fluid level regularly and change it following the owner's manual guidelines. Never go more than a year between oil changes. If you aren't sure what oil type to use, here are recommendations:
  • For ZF 12, 15, 25, 30, 45, 63, 68, 80, and 85 series, and Velvet Drive 71C, 72C, 73C, and 5000 series, use an ATF fluid which meets Detroit Diesel Allison C-4 specifications (e.g.: Dexron IIE, Dexron III).
  • For ZF 220 and larger series, use a marine 30W transmission oil (no/low detergent, not multi-grade). In very hot climates 40W is okay.

Oil Filter
For transmissions with an oil filter, replace it as needed following the owner's manual guidelines. Find replacement oil filters here.

Adapter Housing
The adapter housing is what connects the transmission to the engine bellhousing. You can usually reuse your existing one as long as it is not damaged. If you need a new one, see here for a list of common adapter housings.
Details
BrandYanmar
ColorGray
FitsMechanical Shift
Item Weight21.7 lbs
Made InJapan
ManufacturerKanzaki
Manufacturer #KM2P-1-2.21
ModelKM2P-1
Part Number128171-81310
ReplacesYanmar Kanzaki KM2P
Shipping Dims16" x 16" x 14"
Shipping Weight25 lbs
SizeGear Ratio: 2.21:1 (3.06:1 Reverse)
TypeBoat Transmission, No Down Angle, 0 Degree
UPC443590321184
Warranty1 Year
