Vulkan Marine Damper Plate 1KT3110008 Cummins Deere Boat Diesel Engine ZF
By Vulkan
PART #1KT3110008
WARRANTY1 Year
MADE INGermany
SHIPPING WT19 lbs
SHIPPING DIMS14" x 14" x 4"
$479.63
Free Shipping to the Contiguous 48 US States
(See all shipping options in cart)
6 in stock
Secured by:
Share this product:
PinterestTwitterFacebook
Product Description
New Vulkan 1KT3110008 marine damper plate for standard-rotation marine diesel engines (also called a drive plate or coupling). Fits many Cummins 6BT, 6BTA, John Deere, Caterpillar (Cat), and other diesel boat engines that are standard rotation and have an SAE 11.5 flywheel. For use with 26-spline input shaft, common to many ZF, Hurth, Velvet Drive, and other transmissions. Handles up to 738 lb-ft of torque. Dimensions are 13.126 inch (333.4 mm) bolt center-to-center, 13.874 inch (352.4 mm) overall outside diameter (OD). 8 bolt holes.

Installation note: These are designed for standard-rotation engines only (left-hand, counter-clockwise when viewing the flywheel). The plate must be installed with the arrow showing the direction of rotation. The arrow and part number stamped onto the plate should be facing out from the engine (towards transmission). Incorrect installation will cause the damper to break apart.
Details
BrandVulkan
FitsMarine diesel with SAE 11.5 flywheel & ZF trans
Item Weight16.2 lbs
Made InGermany
ManufacturerVulkan
Manufacturer #1KT3110008
Model1KT3110008
Part Number1KT3110008
ReplacesZF 3205116013
Shipping Dims14" x 14" x 4"
Shipping Weight19 lbs
SizeSAE 11.5"
TypeTorflex 1000 Damper Plate
UPC443590472893
Warranty1 Year
