Velvet Drive 72C 2.57:1 Marine Boat Transmission Gearbox 10-18-010 Borg Warner
By Velvet Drive
Part #10-18-010
Warranty1 Year (6 Month Commercial)
Made InUnited States
Shipping Wt190 lbs

$10,477.65 US

Free Shipping to the Lower 48 US States
Out of stock
Notify when in stock

Product Description

New Velvet Drive marine transmission. Model 10-18-010, series 72C, ratio 2.57:1. Sold by an official Velvet Drive distributor. Set up for standard-rotation (automotive-rotation) engines. Pump can be rotated to go behind non-standard-rotation.

The transmission does not come with any accessories. View these coolers, adapters, or damper plates for additional accessories that you might need.

Important Guidelines
To improve transmission longevity and preserve the warranty, please follow these guidelines when installing and running your new transmission:

Oil Cooler
For transmissions that use an oil cooler, it is important to have it serviced or buy a new one (and flush the oil lines). If there had ever been water, metal particles, or other debris in the old transmission oil, or the old transmission failed or was slipping, reusing an old oil cooler can cause debris to enter the new transmission through the cooler circuit, which can void the warranty and lead to premature failure.

If you need a new oil cooler, you can view a list of coolers here. The oil cooler used by the transmission will vary depending on the engine make and model, so yours may not be listed. Contact for help if needed.

Damper Plate
Also called a drive plate, this bolts to the flywheel and engages the transmission input splines. It dampens the engine torsional firing impulses to protect the transmission. An old, damaged, or worn out damper plate may not dampen the torsionals as well, leading to premature wear and tear, or in the worst case a complete failure. If you need a new damper, you can view a list of dampers here.

If you're changing from a Volvo MS-series transmission to a ZF, you'll also need to switch from the original spring type to a Centa bushing type damper.

Oil Changes & Fluid Types
Check your transmission oil fluid level regularly and change it following the owner's manual guidelines. Never go more than a year between oil changes. If you aren't sure what oil type to use, here are recommendations:
  • For ZF 12, 15, 25, 30, 45, 63, 68, 80, and 85 series, and Velvet Drive 71C, 72C, 73C, and 5000 series, use an ATF fluid which meets Detroit Diesel Allison C-4 specifications (e.g.: Dexron IIE, Dexron III).
  • For ZF 220 and larger series, use a marine 30W transmission oil (no/low detergent, not multi-grade). In very hot climates 40W is okay.

Oil Filter
For transmissions with an oil filter, replace it as needed following the owner's manual guidelines. Find replacement oil filters here.

Adapter Housing
The adapter housing is what connects the transmission to the engine bellhousing. You can usually reuse your existing one as long as it is not damaged. If you need a new one, see here for a list of common adapter housings.
Share this product:

$10,477.65 US

Free Shipping to the Lower 48 US States
Out of stock
Notify when in stock

Product Specifics

BrandVelvet Drive
Made InUnited States
FitsMechanical Shift
Item Weight153 lbs
ManufacturerVelvet Drive
Manufacturer #1018-000-010
MaterialCast Iron
Model1018 72C
Part #10-18-010
Product TypeBoat Transmission, Inline, No Down Angle
ReplacesVelvet Drive 10-18-010, Borg Warner AS14-72C
Shipping Dims28" x 18" x 18"
Shipping Wt190 lbs
SizeGear Ratio: 2.6:1
Warranty1 Year (6 Month Commercial)
